Current Rating Range3-30AInput Voltage rating125 or 250VAC,32VDCWithstand voltage strength1500VAC or 1min The leaked current100MRated short-circuit capacity125VAC or 1000A 250VAC or 1000ARated breaking capacity6times rated currentResetManual Push ResetTripping characteristicsMechanical or Environmental DataOperating Ambient Temperature: -10 to and60 Mounting: Various options. See Ordering Information and drawingsTermination: 250and x27 and x27 (6.35mm)quick connects or solder terminalsCalibration(at25)100 percent of Rated Current: Hold , No Trip 300 percent of Rated Current: 1.5-5.0 sec Trip 200 percent of Rated Current: 5-30 sec Trip 150 percent ofRated Current: Trip Within 1 HourApprovalApproval and File No Rated current Rated voltageCUL UL E155159 3- 30A 125 or 250VAC 50VDCTUV SUD B15 09 58611 007 3-20A 125 or 250VAC 32VDCVDE 40036160 3-16A 125 or 250VACCSA 102199 3-16A 250VACIEC 60934 3-20A 250VACTypical applicationsTarnsforms, Motors, Battery chargers, Power supplies, appliances, extra low voltage systems, machinery
